LED Rolling Display Foldable LED Screen Roll-Up LED Video Screen
LED Rolling Display Thin Flexible Led Screen High Brightness
The thin flexible Foldable LED screen offers a 5-minute quick installation process that can be easily completed by one person in only 3 simple steps.
The thin Roll-Up LED Video screen also features a one-touch remote control that enables automatic lifting and lowering.
The thin flexible LED display is portable and easy to store, making it an ideal choice for events that require quick setup and teardown.
The design of this thin LED display enables easy transportation and installation at a cost-effective foldable LED display price.
The LED video wall has a fast installation process, resulting in a seamless display for your event.
The all-in-one design of the flexible LED screen display eliminates the need for truss and counterweights, simplifying the installation process even further.
The rollable led screen has the ability to display clear and bright images from every angle, positioning it in direct competition with the 360 degree LED screen market.
| LED | NationStar SMD1010 | NationStar SMD1010 | NationStar SMD1010 | NationStar SMD1515 | NationStar SMD2121 |
| Pixel Pitch | 1.25mm | 1.5625mm | 1.953mm | 2.604mm | 3.91mm |
| LED Module Size (mm) | W500 x H62.5 x D14mm | ||||
| LED Module resolution (pixels) | 400 x 50 pixels | 320 x 40 pixels | 256 x 32 pixels | 192 x 24 pixels | 128 x 16 pixels |
| Signal processing capabilities | 14-16 bit | 14-16 bit | 14-16 bit | 14-16 bit | 14-16 bit |
| Grayscale grade | 4096-65536 | 4096-65536 | 4096-65536 | 4096-65536 | 4096-65536 |
| Refresh Rate（Hz） | ≥3840 Hz | ≥3840 Hz | ≥3840 Hz | ≥3840 Hz | ≥3840 Hz |
| Scanning Method | 1/50 | 1/40 | 1/32 | 1/24 | 1/16 |
| Brightness | >800cd/m2 | >800cd/m2 | >800cd/m2 | >900cd/m2 | >1000cd/m2 |
| Best viewing distance (meter) | ≥ 1.2m | ≥ 1.5m | ≥ 1.9m | ≥ 2.6m | ≥ 3.9m |
| Weight | 16kg/㎡ | 16kg/㎡ | 16kg/㎡ | 16kg/㎡ | 16kg/㎡ |
| Viewing angle（°） | 140° | 140° | 140° | 140° | 140° |
| Input voltage（V） | DC 24V | DC 24V | DC 24V | DC 24V | DC 24V |
| Maximum power consumption | 512w/sqm | 512w/sqm | 512w/sqm | 512w/sqm | 512w/sqm |
| Average power consumption | 170w/sqm | 170w/sqm | 170w/sqm | 170w/sqm | 170w/sqm |
| Temperature | -20 ℃/+50℃ (working) | -20 ℃/+50℃ (working) | -20 ℃/+50℃ (working) | -20 ℃/+50℃ (working) | -20 ℃/+50℃ (working) |
| ‐40 ℃/ +60℃ (storage) | ‐40 ℃/ +60℃ (storage) | ‐40 ℃/ +60℃ (storage) | ‐40 ℃/ +60℃ (storage) | ‐40 ℃/ +60℃ (storage) | |
| Protection level | IP 65 / IP 41 | IP 65 / IP 41 | IP 65 / IP 41 | IP 65 / IP 41 | IP 65 / IP 41 |
| Humidity | 10%~90% (working) | 10%~90% (working) | 10%~90% (working) | 10%~90% (working) | 10%~90% (working) |
| 10%~90% (storage) | 10%~90% (storage) | 10%~90% (storage) | 10%~90% (storage) | 10%~90% (storage) | |
| Lifetime（hours） | 100000 | 100000 | 100000 | ≥100,000 | ≥100,000 |
| Maintenance method | Rear | Rear | Rear | Rear | Rear |
| NovaStar Control System | A5S PLUS | A5S PLUS | A5S PLUS | A5S PLUS | A5S PLUS |
